Renishaw RMP600 Radio Transmission Part Probe for Machining Centers

$7,000.00 $6,325.00
SKU:
A-5312-0001

1-2 Business Days

Price and SKU will update based on options selected.
Current stock: 0
Description

Description

The RMP600 is a radio transmission probe using strain gage technology. Measuring only 63 mm in diameter and 76 mm in length, with an omni-directional transmission distance of 15 m, it is ideal for use on all machine tools. RMP600 features an integrated probe module delivering exceptional robustness and generous overtravel. It delivers interferencefree transmission through the use of FHSS (frequency hopping spread spectrum). RMP600 complies with FCC regulations and operates in the 2.4 GHz range.

RMP600 supports three methods of probe activation:
1. Radio-on The probe is turned on via an RF signal produced by the RMI and initiated by an M code. The probe is turned off via an RF signal or the internal timer.
2. Spin-on The probe is turned on via an internal centrifugal switch. The probe is turned off via the centrifugal switch or the internal timer.
3. Switch-on The probe is turned on and off via a switch incorporated into the shank, activated when the probe is loaded into the spindle.


RMP 600 Probe Kit (A-5312-0001)

Includes: RMP600 Probe, 1/2 AA Batter (2), Tool Kit

RMP600 Hardware Only Kit (RMP600-NS-KIT)

Includes: RMP600 Probe, RMI Radio machine interface, Receiver mounting bracket, 50mm and 100mm ceramic styli, Sealtite kit

RMP600 Upgrade Kit (RI-5312-0001)

Includes: RMP600 Probe, RMI Radio Machine Interface, Brackets, sealtite kit

RMP600 Retrofit Kit (RMP600-NS-S)

Includes: RMP600 Probe, Receiver mounting bracket, RMI Radio machine interface, 50mm and 100mm ceramic styli, Sealtite kit, Renishaw Inspection Plus Software, Installation and applications Support

*Must fill out retrofit questionaire before pricing can be given, please contact us for information*

Reviews

Reviews (0)

Be the first to review this product.
Additional Info

Additional Info

SKU:
A-5312-0001
Availability:
1-2 Business Days
Shipping:
$0.00 (Fixed Shipping Cost)
Model:
RMP600
Accuracy Type:
High
