Jet BDB-1340A, 13" x 40" Belt Drive Bench Lathe
$10,348.57
$8,799.00
- SKU:
- JET321360A
Description
Reviews
Additional Info
Description
JET Belt Drive Bench Lathes feature an enclosed gearbox with helical cut gears for noise reduction and smooth operation. The full length splash guard on all sizes prevents hot chips and fluid from contaminating the work area and the quick change gearbox allows for fast and easy gear changes for metric threading. Each JET Lathe comes loaded with features you’ve come to expect, all backed by the industry leading JET Two Year Warranty.
| STOCK NUMBER | 321360A |
|---|---|
| Max. swing over bed (in.) | 13 |
| Max. swing over cross slide (in.) | 7-25/32 |
| Swing Through Gap (in.) | 18-3/4 |
| Length of Gap (in.) | 8 |
| Distance between Centers (in.) | 40 |
| Hole Through Spindle (in.) | 1-3/8 |
| Spindle Mount | D1-4 |
| Spindle Taper | MT-5 |
| Number of Spindle Speeds | 12 |
| Range of Spindle Speeds (RPM) | 60 - 1240 |
| Number of Longitudinal and Cross Feeds (in.) | 38 |
| Range of Longitudinal Feeds (IPR) | .0018 - .0374 |
| Range of Cross Feeds (IPR) | .0006 - .0130 |
| Number of Inch Threads | 38 |
| Range of Inch Threads | 3-1/2 - 80 |
| Number of Metric Threads | 23 |
| Range of Metric Threads (mm) | .45 - 10 |
| Max. Tool Size | 5/8" x 5/8" |
| Max. Compound Slide Travel (in.) | 2-11/16 |
| Max. Cross Slide Travel (in.) | 6-5/16 |
| Max. Carriage Travel (in.) | 35 |
| Tailstock Spindle Travel (in.) | 3-3/4 |
| Taper in Tailstock Spindle | MT-3 |
| Follow Rest Capacity | 2-3/4 |
| Steady Rest Capacity | 2-5/8 |
| Width of Bed (in.) | 7-3/8 |
| Motor | 2HP, 230V, 1Ph |
| Prewired | 230V |
| Net Weight (lbs) | 1175 |
| Overall Dimensions (LxWxH/Inch) | 71 x 32 x 45 |
| BDB-1340A LATHE AND ACCESSORY PACKAGES INSTALLED | STOCK NUMBER |
|---|---|
| BDB-1340A with Acu-Rite Vue 2 Axis DRO & Collet Closer | 321108 |
| BDB-1340A with Taper Attachment | 321120 |
| BDB-1340A with Newall DP700 2 Axis DRO | 321130 |
| BDB-1340A with Acu-Rite Vue 2 Axis DRO | 321110 |
| BDB-1340A with Taper Attachment & Collet Closer | 321112 |
| BDB-1340A with Acu-Rite 200S 2 Axis DRO | 321121 |
| BDB-1340A with Collet Closer | 321111 |
| BDB-1340A with CBS-1340A Stand | 321102AK |
Features
- One of the Most Popular JET Lathes Now Comes with an Enclosed Gear Box
- Enclosed Gearbox Design Provides Smooth, Quiet Operation
- Fast, Easy Speed Changes
- Low Voltage Motor Controls
- Helical Cut Headstock Gears Reduce Noise
- V-Way Bed is Induction Hardened and Ground
- Gap Bed Section Provided for Large Diameter Work
- Independent Leadscrew and Feed Rod
- Spindle Actuation Control is Apron Mounted
- Tailstock May Be Offset for Turning Tapers and Includes an Inch-Metric Graduated Quill
- 6" 3-Jaw Direct Mount Chuck with Top Reversing Jaws
- 8" 4-Jaw Chuck
- 12" Face Plate
- Four-Way Tool Post
- Splash Guard
- Centers and Headstock Center Sleeve
- Threading Dial
- Tool Box with Tools
Reviews (0)
Be the first to review this product.
Additional Info
- Warranty:
- <p><a href="http://content.jettools.com/assets/manuals/321360A_man_EN.pdf" target="_blank">13" x 40" Belt Drive Bench Lathe Manual</a></p>
- SKU:
- JET321360A
- Shipping:
- $0.00 (Fixed Shipping Cost)
- Mfr Part #:
- 321360A
- Style (Type):
- Bench
- Spindle Bore (IN.):
- 1-3/8
- Swing Over Bed (IN.):
- 13
- Distance Between Centers (IN.):
- 40
- Digital Readout:
- Newall DP700
- Digital Readout:
- Acu-Rite 200S
- Digital Readout:
- Acu-Rite VUE
