Heidenhain ND5023 2/3 Axis Mill/Lathe Digital Readout Kit

MTP #:
HEIN-ND5023
Contact Us for Pricing
Quantity:
or View Details
Request Quote

Need Some Advice?Speak to one of our gearheads

Product Description

ND 5023

Axes

Up to 3 axes

Encoder inputs

3 x TTL D-sub, female, 9-pin

Input frequency

≤ 500 kHz

Signal period

2 µm, 4 µm, 10 µm, 20 µm, 40 µm, 100 µm, 10 240 µm, 12 800 µm

Line count

Any

Display step1)

Linear axis: 1 mm to 0.000 1 mm; 0.005 mm with LS 328 C/LS 628 C

Angular axis: 1° to 0.000 1° (00° 00‘ 01'')

Display

7-inch color wide screen (15:9), resolution 800 x 480 pixels for position values, dialog messages,
input and graphic functions

Functions

  • Dialog-guided installation
  • User and data management
  • Moving axis highlighted
  • 10 presets, 16 tools
  • Reference mark evaluation for distance-coded and single reference marks
  • Distance-to-go display with nominal position input in absolute or incremental values
  • Graphic positioning aid
  • Scaling factor
  • mm/inch switchover
  • Integrated help system
  • Stopwatch, calculator

For milling/drilling/boring

  • Calculation of positions for hole patterns (bolt circles, linear hole patterns)
  • Tool radius compensation
  • Cutting data calculator

For turning

  • Freeze tool position during retraction
  • Sum display of axes in the top slide
  • Inclined top slide
  • Taper calculator

Error compensation

Linear (LEC) and segmented linear (SLEC) over up to 200 points

Data interface

USB 2.0 type C

  • For output of measured values and parameters to a USB stick or PC
  • For input of parameters, remote control of keys and commands

Accessories

Single-position tilting base, multi position holder, mounting frame, protective cover, power cable

Power connection

AC 100 V (–10 %) to 240 V (+5 %), 50 Hz to 60 Hz (±5 %), ≤ 33 W

Operating temperature

0 °C to +45 °C (storage temperature –20 °C to +70 °C)

Protection EN 60 529

IP54, back panel IP 40

Mounting

Single position tilting base, multiposition holder; compatible fastening systems to VESA MIS-D 100

Mass

≈ 1.7 kg

Specifications
