Fixed Height Aluminum Gantry Cranes - Vestil Series FHA
Only $2,621.00 - $6,975.00
- SKU:
- RQ-VESL-FHA
Request quote for availability
Description
Reviews
Additional Info
Description
The Fixed Height Aluminum Gantry Cranes are ideal for variety of industries including maintenance and production. The aluminum design is easily manageable and can be simply assembled for immediate use. A fixed height is perfect for working in a permanent or semi-permanent environment where the surrounding seldom change. Casters provide a smooth way to transfer units when unloaded and if changing locations is needed. Four (4) 8" swivel casters with four position locks (2K-4K models have glass filled nylon casters. 6K models have phenolic casters. A strong construction allows for long lasting strength through the harshest of environments.
Vestil Fixed Height Aluminum Gantry Crane Models
| MODEL NUMBER | UNIFORM CAPACITY | OVERALL I-BEAM (LENGTH / HEIGHT) | I-BEAM (FLANGE WIDTH) | UNDER I-BEAM RANGE | BASE WIDTH | WEIGHT (POUND) |
|---|---|---|---|---|---|---|
| FHA-2-8-10 | 2,000 lb. | 96" / 6" | 3 5/16" | 120" | 53 3/4" | 277 |
| FHA-2-10-10 | 2,000 lb. | 120" / 6" | 3 5/16" | 120" | 53 3/4" | 293 |
| FHA-2-12-10 | 2,000 lb. | 144" / 8" | 4" | 120" | 53 3/4" | 315 |
| FHA-2-15-10 | 2,000 lb. | 180" / 8" | 4 3/16" | 120" | 53 3/4" | 405 |
| FHA-4-8-10 | 4,000 lb. | 96" / 8" | 4" | 120" | 53 5/16" | 346 |
| FHA-4-10-10 | 4,000 lb. | 120" / 8" | 4 3/16" | 120" | 53 5/16" | 348 |
| FHA-4-12-10 | 4,000 lb. | 144" / 8" | 4 3/16" | 120" | 53 5/16" | 366 |
| FHA-4-15-10 | 4,000 lb. | 180" / 10" | 4 11/16" | 120" | 53 5/16" | 411 |
| FHA-6-8-10 | 6,000 lb. | 96" / 10" | 4 11/16 " | 120" | 64 11/16" | 599 |
| FHA-6-10-10 | 6,000 lb. | 120" / 10" | 4 11/16" | 120" | 64 11/16" | 494 |
| FHA-6-12-10 | 6,000 lb. | 144" / 12" | 7" | 120" | 64 11/16" | 775 |
| FHA-6-15-10 | 6,000 lb. | 180" / 12" | 7" | 120" | 64 11/16" | 874 |
Check out Vestil Gantry & Jib Crane Catalog
Reviews (0)
Be the first to review this product.
Additional Info
- Warranty:
- <a href="http://www.vestildocs.com/Warranties/Limited%20Warranty%20(90%20days%20warranty%20period).pdf" target="_blank">Vestil FHA Warranty</a>
- SKU:
- RQ-VESL-FHA
- Availability:
- Request quote for availability
- Mfr Part #:
- -
- Construction:
- Aluminum
- Gantry Type:
- Fixed Height
- Height Maximum:
- 10'
- Usable Width:
- 7'
- Usable Width:
- 9'
- Usable Width:
- 11'
- Usable Width:
- 14'
- Capacity Lbs.:
- 2000
- Capacity Lbs.:
- 4000
- Capacity Lbs.:
- 6000
