Economy Lever Hoists (disc brake) - Vestil Series ELH
Only $155.40-$645.80
- SKU:
- RQ_VESL-ELH
Request quote for availability
Description
Reviews
Additional Info
Description
Single hand "free chaining" is simple, allowing trouble-free operation in the vertical or horizontal position. Lever handle can rotate in a complete 360° circle. Swivel hooks include deformation indicators. Each hoist is tested to 150% of rated capacity and issued with an individual test certificate.
Vestil Economy Lever Hoist Models
| MODEL NUMBER | UNIFORM CAPACITY | STANDARD LIFT (FEET) | MINIMUM DISTANCE BETWEEN HOOKS | HANDLE LENGTH | WEIGHT (POUND) |
|---|---|---|---|---|---|
| ELH-15-5 | 1,500 lb. | 5 | 12 7/8" | 11" | 15 |
| ELH-15-10 | 1,500 lb. | 10 | 12 7/8" | 11" | 22 |
| ELH-15-20 | 1,500 lb. | 20 | 12 7/8" | 11" | 23 |
| ELH-20-5 | 2,000 lb. | 5 | 12 3/4" | 11" | 20 |
| ELH-20-10 | 2,000 lb. | 10 | 12 3/4" | 11" | 26 |
| ELH-20-20 | 2,000 lb. | 20 | 12 3/4" | 11" | 32 |
| ELH-30-5 | 3,000 lb. | 5 | 15" | 16" | 28 |
| ELH-30-10 | 3,000 lb. | 10 | 15" | 16" | 34 |
| ELH-30-20 | 3,000 lb. | 20 | 15" | 16" | 45 |
| ELH-60-5 | 6,000 lb. | 5 | 19" | 16" | 46 |
| ELH-60-10 | 6,000 lb. | 10 | 19" | 16" | 50 |
| ELH-60-20 | 6,000 lb. | 20 | 19" | 16" | 65 |
| ELH-120-5 | 12,000 lb. | 5 | 24 7/16" | 16 1/4" | 70 |
| ELH-120-10 | 12,000 lb. | 10 | 24 7/16" | 16 1/4" | 101 |
| ELH-120-20 | 12,000 lb. | 20 | 24 7/16" | 16 1/4" | 107 |
Reviews (0)
Be the first to review this product.
Additional Info
- Warranty:
- <a href="http://www.vestildocs.com/Warranties/Limited%20Warranty%20(90%20days%20warranty%20period).pdf" target="_blank"> Vestil ELH Warranty</a>
- SKU:
- RQ_VESL-ELH
- Availability:
- Request quote for availability
- Mfr #:
- -
- Product Type:
- Hoist
- Capacity Lbs.:
- 1500
- Capacity Lbs.:
- 2000
- Capacity Lbs.:
- 3000
- Capacity Lbs.:
- 6000
- Capacity Lbs.:
- 12000
- Lift:
- 5'
- Lift:
- 10'
- Lift:
- 20'
